Item
|
|
Unit
|
Value
|
Remarks
|
|
|
Working performance
|
Max. rated lifting capacity
|
kg
|
55000
|
|
|
|
|
Max. load moment of basic boom
|
kN.m
|
2009
|
|
|
|
|
Max. load moment of main boom(fully extended)
|
kN.m
|
1050
|
|
|
|
|
Max. load moment of basic boom
|
m
|
12.6
|
|
|
|
|
Max. lifting height of main boom
|
m
|
43.6
|
These parameters do not include deflection of main boom and jib
|
|
|
|
Max. lifting height of jib
|
m
|
58
|
|
|
|
Working speeds
|
Max. hoist rope speed(Main winch)
|
m/min
|
120
|
|
|
|
|
Max. hoist rope speed(Auxiliary winch)
|
m/min
|
120
|
|
|
|
|
Boom demrricking up time
|
s
|
50
|
|
|
|
|
Boom demrricking up time
|
s
|
95
|
|
|
|
|
Slewing speed
|
r/min
|
0-2.2
|
|
|
|
Driving parameters
|
Max. height above sea level
|
m
|
2000
|
|
|
|
|
Max. driving speed
|
km/h
|
76
|
|
|
|
|
Max. gradeability
|
%
|
40
|
|
|
|
|
Min. turning diameter
|
m
|
≤24
|
|
|
|
|
Min. ground clearance
|
mm
|
260
|
|
|
|
|
Oil consumption per hundred kilometers
|
L
|
43
|
|
|
|
Mass
|
Deadweight in driving condition
|
kg
|
42000
|
|
|
|
|
Complete vehicle kerb mass
|
kg
|
41870
|
|
|
|
|
Front axle load
|
kg
|
16000
|
|
|
|
|
Rear axle load
|
kg
|
26000
|
|
|
|
Dimensions
|
Overall dimensions(L×W×H)
|
mm
|
13700×2800×3800
|
|
|
|
|
Outrigger spread(L)
|
m
|
5.92
|
|
|
|
|
Outrigger spread(W)
|
m
|
Fully extended:7.1,intermediately extended:4.8
|
|
|
|
|
Tail slewing radius
|
mm
|
3900
|
|
|
|
|
Main boom length
|
m
|
11.4 - 43.0
|
|
|
|
|
Boom angle
|
°
|
-2 - 80
|
|
|
|
|
jib length
|
m
|
9.2,14.6
|
Low-mounted, open-type
|
|
|
|
Offset
|
°
|
5,25,45
|
|
|
